# T38-405

The Azenta Cryo Freeze Rack is designed to fit in a freezer racking setup for Cryo Freeze Boxes wanting to store sample storage tubes like the Azenta Life Sciences 1.9ml Tri-Coded Sample Tube.  This rack is compatible with a large range of tube formats.

  • Holds 100 tubes in a 10x10 array
  • Open bottom for 2D barcode decoding
  • Compatible with 1.5 and 1.9ml Tri-Coded External Tubes
  • Unique identifier in 1D and 2D format on each freeze box
  • Optimize your storage area by increasing your sample density from 48 to 100 tubes
  • Rack Size: 136.2 x 136.2 x 48.2mm (with lid)
  • Polycarbonate Rack and Lid
  • Min Temperature Range: -196 degrees C (gas phase liquid nitrogen)
  • Max Temperature Range: +130 degrees C
  • Tube Options: 2.0ml External Jacket Tubes, 1.5 & 1.9ml External Next-Gen Jacket Tubes


# P98-872

Designed with the User in Mind:

  • Lightweight, handheld, semi-automatic single column-based capper/de-capper
  • Compatible with 96-SBS rack format screw capped tubes
  • Caps a single column in under 4 seconds; caps/de-caps a complete rack of 96 tubes in less than 90 seconds
  • All caps are tightened to the same torque to create a secure seal
  • Battery operation allows capping/de-capping for more than 40 complete racks
  • Includes docking station for instrument charging and placement/storage for contamination-free handling of caps

 Flexibility for Ease of Use:

  • Single ‘action’ button operation to de-cap, re-cap and eject caps
  • Option to eject caps onto cap carrier using second ‘eject’ button
  • Designed to be used by both left and right-handed users
  • Unit can be operated by battery charge or powered through AC plug in
  • Interchangeable cartridges, easy to switch between cap types

 Specifications:

  • Dimensions (H x W x D): 95 x 50 x 250mm
  • Weight: 380g (including cartridge)
  • Charging Time: Approx. 90 minutes
  • Power Supply: Input: AC 100 - 240V, 50/60Hz 1A-0.45A, Output: 9V DC, 4A
  • Power Jack: USB C
  • Battery: Lithium-ion polymer battery 8.4 V/1500 mAh
  • Operating Temperature: 10 to 35°C
  • Relative Humidity (non-condensing): 10-95%
  • Storage Temperature: -10 to 60°C
  • Includes Decapper, docking station, power cables, operation manual, cartridges for Azenta Internal Thread and External Thread for 96-SBS format racks
